| 122A.02.01-1 | 防水開關 | Waterproof switch |
| 122A.02.02 | 管子 | Pipe |
| 122A.02.04-1 | 水管 | Water pipe |
| 122A.02.001 | 加溫器進水管 | Inlet pipe of the heater |
| 122A.02.002 | 水管 | Water pipe |
| 122A.02.007 | 管子 | Pipe |
| 122A.02.008 | 彈簧 | Spring |
| 122A.02.009 | 彈簧筒 | Spring cylinder |
| 122A.02.011 | 螺釘 | Screw |
| 122A.02.014 | 管子 | Pipe |
| 122.02.01 | 水散熱器 | Water radiator |
| 122.02.02 | 風扇 | Fan |
| 122.02.03 | 管總成 | Pipe assembly |
| 122.02.04 | 加熱器接通開關 | Heater connection switch |
| 122.02.05 | 水管 | Water pipe |
| 122.02.06 | 水管 | Water pipe |
| 122.02.11 | 三通管 | Three-way pipe |
| 122.02.12 | 加熱器出氣管 | Outlet pipe of the heater |
| 122.02.13-3B | 散熱器右護板 | Right guard plate of the radiator |
| 122.02.14-5 | 散熱器下護板 | Lower guard plate of the radiator |
| 122.02.16 | 前集水器 | Front water collector |
| 122.02.17 | 后集水器 | Rear water collector |
| 122.02.18 | 護板 | Guard plate |
| 122.02.21 | 連接管 | Connecting pipe |
| 122.02.23 | 管子 | Pipe |
| 122.02.57-1 | 散熱器后側小護板 | Rear side guard plate |
| 122.02.004 | 水管 | Water pipe |
| 122.02.012 | 旋轉接頭 | Rotary joint |
| 122.02.013 | 空心螺栓 | Hollow bolt |
| 122.02.019 | 管子 | Pipe |
| 122.02.024 | 鋼性彈墊 | Rigid spring pad |
| 122.02.025 | 鋼性彈墊 | Rigid spring pad |
| 122.02.036 | 密封護板 | Sealing guard plate |
| 122.02.037 | 密封護板 | Sealing guard plate |
| 122.02.038 | 密封板 | Sealplate |
| 122.02.040 | 水管 | Water pipe |
| 122.02.041 | 水管 | Water pipe |
| 122.02.042 | 水管 | Water pipe |
| 122.02.043 | 水管 | Water pipe |
| 122.02.044 | 水管 | Water pipe |
| 122.02.045 | 水管 | Water pipe |
| 122.02.047 | 管子 | Pipe |
| 122.02.051 | 管子 | Pipe |
| 122.02.052 | 管子 | Pipe |
| 122.02.053 | 水管 | Water pipe |
| 122.02.054 | 管子 | Pipe |
| 122.02.061 | 散熱器扭桿 | Radiator torsion rod |
| 122.03.01 | 機油箱 | Sump |
| 122.03.02 | 機油散熱器 | Oil radiator |
| 122.03.03 | 雙層油管 | Double-layer oil pipe |
| 122.03.04 | 油管 | Oil pipe |
| 122.03.05 | 油管 | Oil pipe |
| 122.03.06 | 機油散熱器前護板 | Front guard plate |
| 122.03.07 | 機油散熱器后護板 | Car rear trunk security shield |
| 122.03.08 | 油管 | Oil pipe |
| 122.03.09 | 通氣管 | Breather pipe |
| 122.03.10-1 | 機油泵進油轉接管 | Oil inlet transfer pipe |
| 122.03.11 | 接管 | Take over |
| 122.03.17 | 循環機油箱 | Circulating machine oil tank |
| 122.03.18 | 導管 | Catheter |
| 122.03.22 | 機油散熱器左護板 | Left guard plate of the oil radiator |
| 122.03.002 | 通氣管 | Breather pipe |
| 122.03.006 | 彈簧 | Spring |
| 122.03.025 | 襯墊 | Padding |
| 122.03.026 | 襯墊 | Padding |
| 122.03.031 | 集油器 | Oil collector |
| 122.03.051 | 通氣管 | Breather pipe |
| 122.04.01 | 空氣濾清器 | Air filter |
| 122.04F2.01 | 空氣濾清器 | Air filter |
| 122.04.02 | 前閥門 | Front valve |
| 122.04.03 | 后閥門 | Rear valve |
| 122.04.05 | 卡箍 | Clamp |
| 122A.04.06 | 卡箍帶 | Clamp band |
| 122.04.07 | 前一級濾 | Pre-stage filtration |
| 122.04.08 | 頭部總成 | Head assembly |
| 122.04.09 | 后一級濾 | The second-level filter |
| 122.04.11 | 細濾塵盒 | Fine dust filter box |
| 122.04.12 | 粗濾塵盒 | Coarse dust filter box |
| 122.04.010 | 壓圈 | Pressure ring |
| 122.04.007 | 壓板 | Pressure plate |
| 122.04.013 | 螺栓 | Bolt |
| 122.04.017 | 螺桿 | Screw |
| 122.04.018-1 | 旋風筒 | Cyclone cylinder |
| 122.04.018-1/019-1 | 旋風筒/導流管 | Cyclone cylinder/deflector tube |
| 122.04.020 | 上格狀板 | Upper grid plate |
| 122.04.019/020 | 導流管/上格狀板 | Guide pipe/upper grid-shaped plate |
| 122.04.027 | 連接盤 | Connecting disk |
| 122.04.028 | 連接盤 | Connecting disk |
| 122.04.031 | 壓板 | Pressure plate |
| 122.04.033 | 壓板 | Pressure plate |
| 122.04.059 | 銷軸 | Hinge pin |
| 122E.04.01 | 空氣濾清器 | Air filter |
| 122E.04.02-1 | 前密封擋板 | Front sealing baffle |
| 122E.04.03 | 后密封擋板 | Rear sealing baffle |
| 122E.04.06 | 連接管 | Connecting pipe |
| 122A.05.01 | 氣管 | Air tube |
| 122A.05.02 | 卡帶 | Cassette tape |
| 122A.05.03 | 油管 | Oil pipe |
| 122A.05.04 | 油管 | Oil pipe |
| 122A.05.12 | 柴油注油箱 | Diesel fuel tank |
| 122A.05.13 | 右彈架油箱 | Right bomb rack fuel tank |
| 122A.05.14-1 | 氣管 | Air tube |
| 122A.05.15 | 油管 | Oil pipe |
| 122A.05.17 | 小油箱 | Small fuel tank |
| 122A.05.22 | 油管 | Oil pipe |
| 122A.05.27 | 管接頭 | Pipe joint |
| 122A.05.001 | 氣管 | Air tube |
| 122A.05.010 | 油管 | Oil pipe |
| 122A.05.023 | 拉緊螺栓 | Draw-in bolt |
| 122A.05.024 | 銷軸 | Hinge pin |
| 122A.05.044 | 空心螺栓 | Hollow bolt |
| 122A.05.056 | 放油螺塞 | Oil drain plug |
| 122A.05.065 | 緊固螺母 | Tight nut |
| 122.05.01 | 左前柴油箱 | Left front diesel tank |
| 122.05.02 | 右前柴油箱 | Right front diesel tank |
| 122.05.04 | 左彈架油箱 | Left ammunition rack fuel tank |
| 122.05.11 | 油面指示器 | Oil level indicator |
| 122.05.13 | 長卡帶 | Long cassette tape |
| 122.05.14 | 油面指示器開關 | Oil level indicator switch |
